Technical specifications:
- Available Wire Size: 0.1 ~ 2.5mm² (AWG ~ AWG)
- Max. Wire Diameter: Φ4.5mm
- Processing wires: 2 wires (at one time)
- Cutting Length: 0 ~ 99999mm
- Stripping Length: Wire Head 0 - 35mm, Wire Tail 0 - 70mm
- Memory Function: Can store Max. 100 programs.
- Middle Stripping: Max. 16 sections, each place can set stripping length separately!
- Stripping Accuracy:± (0.002mm× Stripping Length)
- Cutting Accuracy:± (0.002mm× Cutting Length)
- Speed: 5000 ~ 8000pcs/hour
- Display: LCD screen with English menu.
- Drive Mode: 4-wheel drive
- Blade Material: Hard tungsten steel
- Power Rating: 300W
- Power Supply: 220V/50Hz 110V/60Hz
- Net Weight: 42Kg
- Dimension: 450 × 365 × 265mm
Advantages of wire stripping and twisting machine KS-09W:
- Extremely perfect effect of twisting wire conductor function makes this machine unique and competitive. KS-09W supports full stripping, half stripping and middle stripping, you may also choose cutting without any form of stripping function.
- Support 3 layers stripping, each layer’s stripping length can be set differently.
- This stripper can store 99 sets of program in the touch screen, which you can retrieve anytime while needed.
- Conduit jumping function allows the conduit to raise while stripping the wire end so that wire end stripping length can reach 70mm.
- Through adjusting pulse value, the machine can reach extremely high precision cutting effect
Delivery method: Nationwide.
- Free in city. HCM
- In the station or express delivery if the customer in outside the province (customers pay shipping costs themselves)
Commitment to customers:
==> Supplying genuine goods (CO / CQ attached), 100% new (with the original belt)
==> Ensure customer's interests when buying products while in warranty, and maintenance for life.
=============== ///=============
