Features of LZS flow meter for corrosive liquids:
- The LZS flow meter for corrosive liquids are made of injection molded, heat and chemically resistant polycarbonate bodies and fittings. Series LFM flowmeters have dual scales measuring in both GPM and LPM with 5% accuracy.
- A textured background on the body enhances scale readability. Standard in-line models come with 1/2" male NPT connections for LFMA, LFMB & LFMC; 3/4" male NPT connections for LFMD; 1" male NPT connections for LFME; and 2" male NPT connections for LFMF.
- Panel mount installation is available with 90° elbow fittings that include panel lock nuts. Various other fittings are available.
Specifications of LZS flow meter for corrosive liquids:
Model | DN | Flow Range | Accuracy | Temperature °C | Pressure Mpa |
GPM | LPM |
LZS-15E | 15 | 0.1-1 0.2-2 0.5-5 | 0.5-4 1-7 1.8-18 | ±4% | 0-60 1-100 | ≤1 |
LZS-15G |
LZS-15EC | 15 | 0.1-1 0.2-2 0.5-5 | 0.5-4 1-7 1.8-18 |
LZS-15GC |
LZS-25E | 25 | 0.8-8 1-10 | 3-30 4-40 |
LZS-25G |
LZS-32E | 32 | 1.2-12 2-20 2.5-25 | 5-50 8-80 10-100 |
LZS-32G |
LZS-50E | 50 | 2.5-25 5-45 7-70 | 10-100 20-180 25-250 |
LZS-50G |
LZS-65E | 65 | 25-110 40-160 50-250 | 80-400 150-650 200-1000 |
LZS-65G |
Delivery method: Nationwide.
- Free in city. HCM
- In the station or express delivery if the customer in outside the province (customers pay shipping costs themselves)
Commitment to customers:
==> Supplying genuine goods (CO / CQ attached), 100% new (with the original belt)
==> Ensure customer's interests when buying products while in warranty, and maintenance for life.
=============== ///=============
